● Suitable for gas applications with pressures up to 500mbar

● Safety cut-off in accordance with EN161, Class A, Group 2

● Suitable for I... Class III gases, i.e. natural gas, city gas, liquefied gas or some special gases

● Double spool structure, small resistance of valve body and large flow rate

● Gas valve diameter from 1/4"... DN40

● Very easy to install on gas pipelines

● It is easy to judge whether the gas valve is open or closed through the yellow power indicator

● The valve position off indicator switch can be integrated into the valve, and the valve status can be judged when the controller is connected

● Plug design, suitable for mass production, improve efficiency

● The flow rate of the gas valve is adjustable

● Low power consumption design, down to 10W

● It can be installed with mainstream gas pressure switches on the market for low pressure, leak detection and high pressure protection

● Bypass valve/ignition solenoid valve can be integrated and installed

● IP65 protection level, can be used in outdoor working conditions

● Valve class A complies with EN161

● Voltage: 230VAC (+10%-15%)

● Permissible medium temperature -15... 60℃

● Protection grade IP65

● Gas type: For 1, 2, 3 gas series and air

                   It is suitable for dry gas with H2S content not exceeding 0.1%.

● Operating environment Operating standard DIN EN 60721-3-3

                                          Climatic conditions Grade 3K5

                                          Mechanical Condition Class 3M2

                                          Temperature range -15...+60°C

                                          Humidity <95%r.F.

● Service life The design life of the combined gas valve is 500,000 times in the normal heating operation mode.
